Conventional Vibration Testing and Control
Mechanical Product Structure Testing and Vibration Research
| Mode | Standard | 10140/10240 | 11140/11240 | 12140/12240 | 13140/13240 | 14140/14240 | 15140/15240 | 16140/16240 | 17140/17240 | 18140/18240 |
| High-end | J10130/J10230 | J11130/J11230 | J12130/J12230 | J13130/J13230 | J14130/J14230 | J15130/J15230 | J16130/J16230 | J17130/J17230 | J18130/J18230 | |
| Feature Description | Titanium alloy housing; standard output options: top/side; additional options: low-frequency extension, high-temperature environment, waterproof integrated cable | |||||||||
| Dimensions mm (Hex x H) | 9.5x18 (M5 top) / 9.5x11 (5-44 side) | 11x19 (M5 top) / 11x15 (M5 side) | 13x21 (M5 top) 13x16 (M5 side) | 16x26 (M5 top) 16x21 (M5 side) | 19x35 (M5 top) 19x28 (M5 side) | 34x43 (M5 top) 34x37 (M5 side) | ||||
| Sensitivity (mV/g) | 5 | 10 | 20 | 50 | 100 | 200 | 500 | 1000 | 5000 | |
| Measurement Range (g peak) | ±1000 | ±500 | ±250 | ±100 | ±50 | ±25 | ±10 | ±5 | ±1 | |
| Amplitude Linearity | ≤±1% | |||||||||
| Broadband Resolution (g rms)） | 0.001 | 0.0005 | 0.00025 | 0.0001 | 0.00005 | 0.000025 | 0.00001 | 0.000005 | 0.000001 | |
| Frequency Range | ±5%(Hz~kHz) | 1~10 | 1~8 | 1~6 | 1~5 | 0.1~2.5 | 0.1~1 | |||
| ±10%(Hz~kHz) | 0.5~12 | 0.5~10 | 0.5~8 | 0.5~7 | 0.06~4 | 0.06~1.2 | ||||
| ±3dB(Hz~kHz) | —— | —— | —— | —— | —— | —— | —— | —— | —— | |
| Installation Resonant Frequency (kHz) | ≥65 | ≥65 | ≥65 | ≥44 | ≥23 | ≥26 | ≥17 | ≥13 | ≥5 | |
| Transverse sensitivity | ≤5% | |||||||||
| Power Supply (VDC) | 18~30 | |||||||||
| Supply Current (mA) | 2~20 | |||||||||
| Output Impedance (Ω) | ≤100 | |||||||||
| DC Bias Voltage (V) | 8~12 | |||||||||
Electrical Noise Power Spectral Density (μg/√Hz) | 10Hz | 240 | 120 | 60 | 24 | 12 | 6 | 2.4 | 1.2 | 0.24 |
| 100Hz | 80 | 40 | 20 | 8 | 4 | 2 | 0.8 | 0.4 | 0.08 | |
| 1000Hz | 60 | 30 | 15 | 6 | 3 | 1.5 | 0.6 | 0.3 | 0.06 | |
| Install Insulation Resistance | —— | —— | —— | —— | —— | —— | —— | ≥1x108 | ≥1x108 | |
| Maximum Withstand Acceleration Value (g peak) | 4000 | 3000 | 2000 | 800 | 400 | 200 | 80 | 40 | 8 | |
| Maximum Withstand Impact Value (g peak) | 8000 | 8000 | 5000 | 2000 | 1000 | 500 | 200 | 100 | 20 | |
| Operating Temperature (°C) | -50~125 | |||||||||
| Sealing Form | Laser Welding | |||||||||
| Sensitive Materials | Standard/High-end Piezoelectric Ceramic/Shear | |||||||||
| Case material | Titanium Alloy | Standard: Stainless Steel High-end: Titanium alloy | Stainless Steel | |||||||
| Installation Method_Internal Threaded Screw Hole | M3-M5 | M5 | ||||||||
| Weight (grams) | 3.5 | 3.5 | 3.8 | 6.2 | 6.3 | 10.5 | 23 | 68 | 365 | |
| Sensor Output Format | 1x140/J1x130 M5 Top Output 1x240/J1x230 5-44 Side Output | 1x140/J1x130 M5 Top Output 1x240/J1x230 M5 Side Output | ||||||||
| Cable end connector type | M5—BNC（511xx12）；5-44—BNC（534xx12） | |||||||||
Common Cable Options Cable Description (Model) | * Cable end connectors: 5-44—BNC: Φ1.6mm TPV cable (5344912); Φ1.6mm PTFE high-temperature cable (5342112) * Cable end connectors: M5—BNC: Φ3mm PVC cable (5114312); Φ3mm TPV cable (5112312); Φ2mm PTFE high-temperature cable (5111212) | |||||||||
| Standard Attachments | ① M3-M5/M5 mounting screws; ② Standard 1-meter PVC coaxial cable; ③ Factory inspection report | |||||||||
| Other Options | * Model + "E": Optional output connector with 10-32 UNF thread * Model + "H": Upgraded high-temperature sensor, operating temperature -50-160℃ * Model + "L": Low-frequency extension, 5%-0.5 Hz * Model + "F": Optional 5m/10m waterproof cable (IP68) (Note: The high-frequency cutoff frequency of the frequency response may change due to the integrated cable. The specific high-frequency cutoff frequency will be based on the sensor test report.) Optional waterproof integrated cable, original hex size adjusted from 9.5mm to 11mm; 5-44 side output series cannot be equipped with waterproof integrated cable. | |||||||||
